Ministernotomy approach for modified Blalock-Taussig shunts in neonates: a feasibility study

Abstract

Background

The original approach to performing a modified Blalock-Taussig (MBT) shunt is via a left thoracotomy. However, the median sternotomy has become the preferred approach of many surgeons. We think that the upper ministernotomy approach provides several advantages and avoids the disadvantages of both the sternotomy and thoracotomy approaches. Here, we describe our experience in constructing neonatal MBT shunts via upper ministernotomy.

Methods

A prospective study was conducted on 50 neonates who underwent modified Blalock-Taussig shunt performed through upper ministernotomy between March 2011 and December 2016. Preoperative characteristics, mortality, and morbidity were recorded.

Results

Mean age was 16.9 ± 10.4 days, and weight was 3.5 ± 0.5 kg. All patients received grafts of size 3.5 mm. The mean oxygen saturation increased from 59.5 ± 7.3% preoperatively to 84.8 ± 4.2% postoperatively. There were three cases of mortality (6%). One patient suffered from an unstable sternum (2%). No patients required conversion to full sternotomy. Superficial wound infection occurred in three cases (6%), and there were no cases of mediastinitis. Mean duration of ventilation was 55.64 ± 37.5 h, mean ICU stay was 5.44 ± 3.9 days, and mean hospital stay was 14.7 ± 7.2 days.

Conclusion

Upper ministernotomy is a safe approach with good early results. It provides adequate exposure with limited surgical trauma. Emergency conversion to full sternotomy and initiation of cardiopulmonary bypass can be achieved easily. It avoids lung compression and respiratory compromise. Additional costs for specific instruments are not necessary.

Background

In the current era, biventricular corrective surgery is the preferred approach for neonates or young infants, whenever possible. However, palliative systemic-pulmonary arterial shunt is still needed in cases of single ventricle physiology, reduced pulmonary blood flow with vital instability, and in resource-limited regions where funding for open heart procedures, especially in such high-risk patient groups, is not available.

The modified Blalock-Taussig (MBT) shunt was introduced as one of many options for connecting the systemic and pulmonary circulations and involves a polytetrafluorethylene (PTFE) tube graft being inserted between the subclavian and pulmonary arteries. It has become a widely accepted palliative procedure due to the low morbidity and mortality rates associated with the procedure [1,2,3].

The original approach for the MBT shunt, as described by de Leval and co-workers, was via a left thoracotomy [4]. However, in recent times, the median sternotomy has evolved to become the preferred approach of many surgeons. Some of the reasons for this include the following: it is a less demanding operation, it provides greater control of the blood vessels without the risk of respiratory compromise due to lung compression, and it enables construction of the anastomosis at the side of the superior vena cava for possible correction of pulmonary artery distortion during later conversion to the bidirectional Glenn [5]. However, subsequent procedures require repeat sternotomy, which is more time consuming and carries greater risk due to sternal adhesions.

The upper ministernotomy approach to MBT shunt construction has not been described in the literature. We believe that it can provide adequate exposure and easy construction of an anastomosis and carries less risk for subsequent sternal re-entry. In this report, we study the feasibility of MBT shunt construction in neonates via upper ministernotomy. Our endpoints include mortality and morbidity in terms of sternal stability, pulmonary mechanics reflected by the presence of lung collapse and duration of mechanical ventilation, and superficial and deep wound infections.

Methods

Preoperative characteristics

After receiving approval from the local ethics committee in Faculty of Medicine at Ain Shams University, a prospective study was conducted on 50 successive neonate patients between March 2011 and December 2016. All neonates who presented with desaturation due to decreased pulmonary blood flow and scheduled for an MBT shunt were included in the study. Patients who required cardiopulmonary bypass for other concomitant procedures, such as pulmonary artery reconstruction, unifocalisation of collaterals, and Norwood, were excluded from the study. However, off-pump pulmonary artery reconstruction was not an exclusion criterion.

Preoperative diagnoses are summarised in Table 1.

Table 1 Preoperative patient characteristics

All patients underwent regular preoperative medical examination and laboratory investigations. Informed written consent was obtained from each patient’s guardian(s).

Diagnosis was achieved via echocardiographic and multislice computed tomography (MSCT) examinations to establish the intracardiac anatomy, the systemic and pulmonary vessel distribution and dimensions, and the presence, site, and size of patent-ductus arteriosus (PDA).

Operative procedure

All patients received intramuscular ketamine (3 mg/kg) for sedation and stress-free separation from their parents. In the operating room, patients were monitored using five-lead ECG, pulse oximetry (SpO2), capnography for end-tidal carbon dioxide (Drager PM 8040-CATO, lübeck, Germany), planter surface temperature, and invasive blood pressure. Central venous catheters and arterial catheters were inserted after induction of general anaesthesia. Mechanical ventilation was provided by a Narkomed anaesthesia machine (North American Drager, Telford, PA) with fractional inspiratory oxygen concentration (fiO2) maintained 0.9 and 1.0. The end-tidal carbon dioxide (CO2) was maintained between 35 and 40 mmHg, using a tidal volume of 10 mL/kg and respiratory rate adjusted according to age. Positive end-expiratory pressure of 2–5 cmH2o and inspiratory to expiratory ratio (I:E ratio) of 1:1.5–1:2 were used.

All MBT shunt procedures were performed via upper ministernotomy. A small skin incision was made from 0.5 cm below the suprasternal notch to 1 cm below the sternal angle. Then, the manubrium and the sternum were divided longitudinally in a J-shaped manner, using Mayo scissors up to the level of the third right intercostal space. After opening the sternum, the right lobe of the thymus was excised; the innominate artery was dissected up to its branches, with dissection of the right subclavian artery. The pericardium was opened above the aorta and stay sutures were inserted. The right pulmonary artery, between the ascending aorta and the superior vena cava up to the upper lobar branch, was dissected.

The systemic site of the shunt insertion was either the innominate or right subclavian artery, and the site of the distal anastomosis was the right pulmonary artery as close to the middle line as possible.

The systemic artery was partially clamped with a Cooley clamp, and a longitudinal arteriotomy was performed at the undersurface of the artery. A transversely cut polytetrafluoroethylene (Gore-Tex) tube graft (W. L. Gore & Associates, Inc., USA) was sutured end-to-side to the arteriotomy. The clamp was then released in situ to ensure good shunt flow and a competent anastomosis. The systemic artery was clamped again, and the shunt was flushed by heparinised saline to flush any thrombi, then the shunt was trimmed to the appropriate length. The right pulmonary artery was partially clamped with a Cooley clamp, and an end-to-side distal anastomosis was performed in the same way (Figs. 1, 2, and 3).

Fig. 1
figure1

Operative view showing the right pulmonary artery via the ministernotomy approach. RPA right pulmonary artery

Fig. 2
figure2

Operative view showing the right subclavian artery via the ministernotomy approach. SCA subclavian artery

Fig. 3
figure3

Operative view of the MBT shunt constructed via upper ministernotomy in a neonate patient

All neonates in this series received 3.5-mm grafts, and the ductus was not ligated.

Before closure, haemostasis was secured, and a retrosternal drain was inserted

Postoperative events

Postoperatively, all neonates were ventilated. After haemostasis was ascertained, heparin was administered as a continuous infusion at 10–20 units/kg/h and was later changed to an oral low dose of aspirin (5 mg/kg/day). All patients received a postoperative echocardiographic examination to check the patency of the shunt

Study endpoints

Study endpoints were in-hospital mortality, reoperation for immediate shunt-related complications (thrombosis or anastomotic stenosis), conversion to full sternotomy, duration of ventilation, intensive care unit (ICU) stay, hospital stay, postoperative peripheral oxygen saturation (SaO2) at discharge, and postoperative complications in terms of respiratory failure, re-exploration for bleeding, unstable sternum, superficial wound infections, and mediastinitis.

Statistical analysis

The collected data were revised, tabulated, and analysed using Statistical package for Social Science (SPSS) version 25 (SPSS, Inc., Chicago, IL, USA). Statistical data were expressed as mean ± standard deviation (SD) for continuous variable or as value and percentage for categorical data.

Results

All 50 patients were enrolled in the study. No patient required conversion to full sternotomy or emergency cardiopulmonary bypass. The mean age of the patients was 16.9 ± 10.4 days, and the mean weight was 3.5 ± 0.5 kg.

Mortality

There were three in-hospital deaths (6%). The causes of death were low cardiac output, sepsis, and acute respiratory distress syndrome (ARDS).

Outcomes

The mean preoperative SaO2 was 59.5 ± 7.3 %, and the postoperative saturation was 84.8 ± 4.2%. The mean duration of ventilation was 55.64 ± 37.5 h, mean ICU stay was 5.44 ± 3.9 days, and the mean hospital stay was 14.7 ± 7.2 days.

Morbidity

Shunt thrombosis occurred in two (4%) patients who needed shunt revision and the graft was replaced with one of the same size. Shunt overflow was reported in five cases (10%), and there were no cases of shunt failure due to small shunt size. One case had an unstable sternum after re-exploration for shunt revision. The stainless wires were broken, and re-exploration was required for sternal fixation. No cases required re-exploration for bleeding. Superficial wound infection occurred in three patients (6%), which were all treated properly by repeated dressing changes and antibiotics. There were no cases of mediastinitis (Table 2).

Table 2 Mortality and morbidity

Discussion

Minimal-access approaches have become more popular and widely used in paediatric cardiac surgery in recent times. They reduce surgical trauma, morbidity, and length of hospital stay. They have been reported to be associated with less blood transfusion and less postoperative pain [6,7,8]. There are several incision options for different minimally invasive approaches, based on the operation needed, including the parasternal incision, lateral thoracotomy, and upper or lower partial ministernotomy. The main concepts for all approaches are to provide adequate surgical exposure and the certain safety of the procedure [9]. MBT shunt was classically performed via the thoracotomy approach. Although it is a minimal access incision that gives good surgical exposure and adhesion-free mediastinum on subsequent sternotomy, it does not provide complete safety of the procedure in terms of overlooking some cardiac anomalies that may be missed in the preoperative diagnosis. In addition, it lacks the cosmetic advantage by making a second scar on the chest. It also has potential disadvantages, such as chylothorax, pulmonary artery distortion, and preferential pulmonary blood flow [1]. Many authors have reported the advantages of the sternotomy approach for MBT shunt; it provides good exposure of the vessels, easy control of patent ductus arteriosus, initiation of cardiopulmonary bypass if necessary, and easy takedown of the shunt and reconstruction of the pulmonary artery during later procedures. Moreover, it avoids lung compression, respiratory compromise, late scoliosis, and a second chest scar [1, 3, 10, 11].

We aimed to provide the advantages but avoid the disadvantages of both sternotomy and thoracotomy approaches, via a minimal access upper ministernotomy approach. We found adequate exposure for construction of the MBT shunt, and we did not need any special instruments or devices. Thorough exploration of other cardiac defects, pulmonary artery branch size and distribution, and patent ductus arteriosus was easily carried out. Conversion to full sternotomy and initiation of cardiopulmonary bypass is also possible; however, it was not needed in our study.

Many authors have reported advantages of ministernotomy compared to median sternotomy, including less surgical trauma, less blood transfusion, less postoperative pain, better recovery, and shorter hospital stay [6, 7, 9, 12]. Nevertheless, others disagree and have reported contrary results, for example, Aris et al. [13] reported that ministernotomy did not reduce the length of hospital stay, postoperative pain, or bleeding, and Laussen and colleagues [14] failed to demonstrate better patient recovery in minimally invasive incisions.

We did not objectively assess postoperative pain or pulmonary function because they are difficult to measure in this age group. However, diminished surgical trauma and nearly intact chest cage resulted in good patient recovery and respiratory mechanics. This can be noticed in the average results for mechanical ventilation, ICU stay, and length of hospital stay.

All MBT shunt patients will require a second procedure for biventricular repair or Fontan operation. Therefore, the ministernotomy approach in such patients has a peculiar advantage as it exposes only a limited portion of the great vessels, thereby saving the cardiac chambers, especially the right ventricle. Therefore, it results in fewer sternal adhesions, minimising the risks of cardiac injury and blood loss on sternal re-entry. Moreover, subsequent operation(s) with a single scar on the chest provide a cosmetic advantage. The smaller surgical incision results in limited soft tissue dissection with reduced risk of postoperative soft tissue infections and mediastinitis [15], and this explains our results that show a low incidence of superficial soft tissue infection and no cases of mediastinitis.

Study limitations and future prospective

This was a prospective feasibility study to show that the procedure is possible with no major complications. The number of patients in the study was limited, and the study focused on only the short-term outcomes. Further studies are needed to compare this approach with others and to report the long-term follow-up and the potential advantages of the ministernotomy approach in the second stage operations.

Conclusion

Upper ministernotomy is a safe alternative approach for MBT shunt in neonates. It provides the advantages of adequate exposure with less surgical trauma. It avoids lung compression and respiratory compromise, and there is no technical compromise in the construction of the anastomosis. In addition, extra costs for specific instruments are not necessary. Further comparative studies with long-term follow-ups are essential.
